3-Piece Ball Valve

Bray

Price:
Sale price$0.00

Description

:The Series 7000/8000 3-piece ball valves offer the highest flexibility in the Bray product line for selection of end connections, seat materials and three piece design. To meet customer demands for a valve with the widest possible range of applications, these valves can be fitted with control or tri-ported balls (for full cavity drainage), as well as cavity fillers for special service requirements.

Features:

    • Size Range: NPS 1/4" to 12 / DN 8 to 300
    • Body Materials: Series 7000: CF8M, Series 8000: WCB
    • Temperature Range:  -50°F to 550°F (-46°C to 287°C)
    • Stem Material: 316 Stainless Steel
    • Maximum Allowable Operating Pressure:
      • NPS ¼ to 4: 1000 psi CWP (DN 8 to 100: 69 Bar),
      • NPS 6 to 12: 400 psi CWP (DN 150 to 300: 27 Bar)
    • End Connections:
      • Threaded ASME B1.20.1 NPT, Socket Weld ASME B16.11
      • Butt Weld MSS SP-72 /ASME B16.25, Flanged ASME Class 150
      • Extended Socket Weld
      • Extended Butt Weld
    • Certifications:
      • 7000/8000 - ATEX, CRN, PED, PE(S)R, TR CU, SIL
      • 7000 - NSF 61/372
